Behringer Ultra-Drive Pro DCX2496 Loudspeaker Management System

Behringer Ultra-Drive Pro DCX2496 Loudspeaker Management System

Regular price $550.00 USD
Regular price Sale price $550.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

Product description

The Behringer Ultra-Drive Pro DCX2496 is your workhorse tool for the exacting set-up of multiple loudspeaker systems or arrays. The DCX2496 gives you superb AKM 24-bit/96kHz digital converters for exceptional signal integrity and a robust dynamic range of 113dB. You also get four different mono and stereo output operating modes, your choice of Butterworth, Bessel and Linkwitz-Riley filters, adjustable delays for all inputs and outputs, limiters across all output channels, and a potpourri of EQ options. If you've got a passel of loudspeakers to manage, you need Behringer's Ultra-Drive Pro DCX2496.

Amazon.com

The ULTRADRIVE PRO DCX2496 is the ultimate digital loudspeaker management system with an unheard-of audio quality and feature list. It is an indispensable tool for the precise set-up of multiple loudspeaker systems or arrays. Installation contractors, live-sound engineers, cinemas/discotheques/concert hall operators will quickly learn to love this model's rich features. Signals can be split in various ways to assure precise sound by using the optimal frequency range of each loudspeaker.

Configure using the device or take advantage of Windows-based editing software.

Three analog inputs and six analog outputs for maximum flexibility. Click to enlarge.

Maximum Flexibility
Start with its 3 analog inputs (one suitable as a digital stereo AES/EBU input) and 6 analog outputs. You get maximum flexibility in just one rack space. Superb high-end AKM 24-bit/96 kHz A/D and D/A converters give you ultimate signal integrity and an extreme dynamic range of 113 dB. Easy connection of external digital signals with sampling rates from 32 to 96 kHz is a breeze with the integrated sample rate converter. There are precise dynamic EQs for level-dependent equalization and extremely musical parametric EQs, selectable for all inputs and outputs, and "Zero"-attack limiters on all output channels guarantee optimal signal and loudspeaker protection.

You also get four different mono and stereo output operating modes, all with individual crossover filter types (Butterworth, Bessel and Linkwitz-Riley) with selectable roll-off characteristics from 6 to 48 dB/octave. The delays for all inputs and outputs are adjustable. This allows you to manually or automatically correct for room temperature, phase and arrival time differences. An additional sum signal is easily derived from the A/B/C inputs.

Remote Ready
Now that remote control is such a hot topic, you'll be glad that the future-proof ULTRADRIVE PRO software enables single or multi remote control via PC through RS-232 and RS-485 interfaces. And the link option via RS-485 network interface enables cascading of several ULTRADRIVE PROs. A Windows-based editing software is available for download free of charge. No matter what the future brings, its open architecture assures easy software updates. A PCMCIA slot allows you to store all your settings and recall them anytime you change the location--virtually taking your ULTRADRIVE PRO with you.

Pure Performance
The ULTRADRIVE PRO's high-power 32-bit SHARC-DSP and ultra-high resolution CRYSTAL/AKM A/D & D/A converter provide outstanding audio performance--and the servo-balanced, gold-plated XLR connectors for all inputs and outputs guarantee excellent connectivity for the years to come.

What's in the Box
Behringer DCX2496, Power Cable, User's Manual


  • Output Channel Limiters
  • Adjustable Delays
